Mining Equipment Conical Gear Straight Bevel Gear 14 Module with Gear Shaping

Name: Mining Equipment Conical Gear Straight Bevel Gear 14 Module with Gear Shaping
Brand: YZGEAR
Price: 300.0 USD

Buy cheap Mining Equipment Conical Gear Straight Bevel Gear 14 Module with Gear Shaping product

Brand Name : YZGEAR

Model Number : BG220804004

Place of Origin : CHINA

MOQ : 1 Set

Price : $300.0/Set

Payment Terms : L/C, D/P, T/T, Western Union

Supply Ability : 200 Sets/Month

Delivery Time : 55 Days

Packaging Details : Plywood Crate

Module : 16

Pitch : 5.09

Inner Diameter : 320

Gear Quality : ISO 8-9 Grade

Tip Diameter : 820mm

Brand : OEM

Contact Now

Straight Crow Gear of Mining Equipment-Conical Gear-Straight Bevel Gear

1) Description of Straight Bevel Gear

Stright bevel gear with gear teeth have tapered conical elements that have the same direction as teh pitch cone line.

Bevel gears transfer the energy from linear to vertical power, making it very useful in machines widely used in mechanical settings.

2) Feature of Straight Bevel Gear

Straight bevel gear is easy to manufacture and most widely used compared with other type bevel gears.
Straight bevel gear makes it possible to change the operating angle.

Technical Specifications

Parameter	Specification
Custom Made	Available
Gear Profile Type	Gleason
Manufacturing Process	Gear Shaping
Teeth Grinding	Included
Module (M)	14
Number of Teeth (Z)	26/60
Pressure Angle (α)	20°
Lead Angle	Custom
Accuracy Grade	ISO 8-9 Grade
Heat Treatment	Carburizing/Induction Hardending
Surface Hardness	Pinion 58-62 HRC/Gear 50-55 HRC

Steel Code Grades Comparison

CHINA/GB	ISO	ГΟСТ	ASTM	JIS	DIN
45	C45E4	45	1045	S45C	CK45
40Cr	41Cr4	40X	5140	SCr440	41Cr4
20CrMo	18CrMo4	20ХМ	4118	SCM22	25CrMo4
42CrMo	42CrMo4	38XM	4140	SCM440	42CrMo4
20CrMnTi		18XГT		SMK22
20Cr2Ni4		20X2H4A
20CrNiMo	20CrNiMo2	20XHM	8720	SNCM220	21NiCrMo2
40CrNiMoA		40XH2MA/40XHMA	4340	SNCM439	40NiCrMo6/36NiCrMo4
20CrNi2Mo	20NiCrMo7	20XH2MA	4320	SNCM420

Production Equipment

Mining Equipment Conical Gear Straight Bevel Gear 14 Module with Gear Shaping

Manufacturing Process

Mining Equipment Conical Gear Straight Bevel Gear 14 Module with Gear Shaping
